BE-IRD-5503 Integrated Receiver/Decoder

The BE-IRD-5503 is a versatile third generation 5500-class integrated receiver and decoder for broadcasters, cable operators, and telecoms with Genlock capability for accurate frame and color synchronization. A highly flexible professional choice, the 5503 can decode all video formats (HD or SD, MPEG-2 or MPEG-4), making it the perfect solution for customers migrating from MPEG-2 SD to MPEG-4 HD. A wide range of input/output options, together with a built-in Multiplexer/Filter, allows users to create highly customized transport streams. Two PCMCIA Common Interface card slots support a variety of Conditional Access systems, including Conax, Cryptoworks, Irdeto, Mediaguard, NDS, SECA, Viacross, and others. LAN control and monitoring can done using the unit's built-in Monitor Center facility, or through standard SNMP-based network management systems.

Tuner / Input Specifications (select one)

  • DVB-S/S2 QPSK & 8PSK Demodulation complies with DVB-S, MPEG-2, ETSI 300421 standards
    • Input frequency range: 950~2150MHz
    • Input Level: -25dBm~65dBm
    • Input Impedance: 75, F type female connector
    • Symbol Rate: 2~45Mb/s (SCPC or MCPC)
    • Rolling Off Factor: 0.35 for QPSK; 0.35, 0.25, 0.2 for DVB-S2
    • Punctured Rates:
      1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 8/10 for DVB-S QPSK
      3/5, 2/3, 3/4, 5/6, 8/9, 9/10 for DVB-S2 8PSK
    • LNB Level: 0, 13V, 18V adjustable
    • Reed Solomon Error Correction: 204, 188, T = 8 & I = 12
  • DVB-C QAM Demodulation complies with DVB-C & MPEG-2 standards
    Tuner
    • Input Symbol Rate Range: 1~7Mbps (PAL), 1~6Mbps (NTSC)
    • Demodulation: 16/32/64/128/256QAM
    • Bandwidth: 6, 7, 8MHz
    Input
    • Frequency Range: 48~860MHz
    • Digital Signal Input Level: -15~15dBmV
    • Input Impedance: 75, IEC Female (7/8MHz) or F Female (6MHz) Input
  • DVB-T/T2 COFDM Demodulation complies with DVB-T & MPEG-2 standards
    Tuner
    • Input Symbol Rate Range: 4.98~31.67Mbps (8MHz bandwidth)
    • Demodulation: QPSK, 16 QAM, 64 QAM
    • Bandwidth: 6, 7, 8MHz
    • FFT Mode: 2K/8K
    • Guard Interval: 1/4, 1/8, 1/16, 1/32, off
    • FEC Code Rate: 1/2, 2/3, 3/4, 5/6, 7/8
    Input
    • Frequency Range: 470-862MHz (UHF), 174-230MHz (VHF)
    • Digital Signal Input Level: -20~-70dBmV
    • Input Impedance: 75, IEC Female (7/8MHz) or F Female (6MHz) Input
  • DS3 Input & Loop-through Output compatible with Barco, Huawei, etc. protocols
    • Impedance: 75
    • Connector: BNC
    • Maximum Input Code Rate: 44.736Mbps
    • Format: Unframed Framing according to G.804 / G.752 (DS3) / G.703 E1/E3

TS over IP Output

  • 10/100base-T: RJ45
  • Maximum Output Code Rate: 70Mbps
  • UDP/RTP: Multicast or Unicast
  • Multicast Control Protocol: IGMPV2

Input Connectors

  • 1 IP input — RJ45 connector (Gigabit Ethernet, shared with output)
  • 1Ethernet management port — RJ45 connector
  • 1 ASI — BNC connectors
  • 1 RF Tuner
  • 1 Genlock reference input (B.B./Tri-s Frame Sync)

Output Connectors

  • 1 IP output — RJ45 connector (Gigabit Ethernet, shared with input)
  • 1 RS-232 printing port
  • 2 ASI — BNC connectors
  • 2 SDI — BNC connectors
  • 1 HDMI
  • 1 component video — Y Pb Pr set of RCA connectors
  • 1 composite video — BNC connector
  • 1 composite video — RCA connector
  • 2 DB-9 connectors for 2 digital AES/EBU & 2 analog XLR audio stereo pairs
  • 1 RF Tuner loop-out

Physical Specifications

Input voltage:
AC 90V~260V, 50/60Hz, 50W (max); DC -48V
Dimensions & Weight:
1RU (H) / 19 (W) x 10 (L) in / 483 (W) x 255 (L) mm
11 lbs / 5 Kg
Operating Conditions:
Temperature 0~45°C; Humidity 95%
Storage Temperature:
20~70°C
BE-IRD-5503

Applications

The Telairity BE-IRD-5503 offers professional receive, decode, decrypt, and descramble capabilities for all broadcast applications, including IP, Satellite, and Cable head-end facilities. Supports:

  • IPTV
  • All types of head-end facilities
  • HD/SD ENG/SNG Receiving
  • HD/SD Program Distribution

Benefits

Part of the Telairity family of

professional video compression

products for trouble-free integration

with Telairity encoders.

Decodes all 4:2:0 formats:

HD & SD, MPEG-2 & H.264/AVC

HD to SD down-conversion;

Convert DVB to/from IP;

Convert other TS formats to DS3

QPSK / 8PSK, QAM, or COFDM

input interface with error correction;

source loop-out over 75 cable

Option to replace DVB interface with

DS3 (G.703, E1/E3) interface

IP interface standard on all models;

configurable for input or output

Genlock reference input

2 CI slots to accommodate a variety

of CA systems

Supports BISS/BISS-E descrambling

IP, ASI, SDI, HDMI, Component, and

Composite video outputs

Decodes up to 6 audios with analog,

digital, and embedded output; 2 AC3

pass-through audios supported

Built-in multiplexer/filter

Teletext, VBI, EBU and DVB

subtitles; WSS and Closed Caption

Includes alarm relay; auto-saves

settings on power loss

Ordering Information

Part Number: BE-IRD-5503

Contents

  • IRD 5000-series Decoding Platform
  • CD with management software
  • User Manual (hardcopy)
  • Cables
    • Power cord (IEC to USA plug)
    • RCA A/V cable
    • BNC cable
    • RS-232 to XLR

Requirements

  • PC for control system
  • Encoded source
  • Display to view decoded images

System Control

  • LCD panel menus
  • Network control software (on CD)
  • SNMP-based network management systems
